| Donanım Özellikleri |
| Standartlar |
IEEE 802.11b/g/n Wireless LAN
IEEE 802.11i Wireless Security
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af/at Power over Ethernet / PD |
| Hafıza |
32 Mbytes DDR SDRAM
8 Mbytes Flash |
| Arayüz |
Wireless IEEE 802.11b/g/n, 2T2R
LAN: 1 x 10/100Base-TX, Auto-MDI / MDIX, IEEE 802.3af/at PoE / PD port
WAN: 1 x 10/100Base-TX, Auto-MDI / MDIX |
| Anten |
N-Type Female connectors x 2 |
| Kablosuz RF Özellikleri |
| Kablosuz Standartları |
IEEE 802.11b/g
IEEE 802.11n |
| Data Hızı |
IEEE 802.11b: 11, 5.5, 2 and 1Mbps
IEEE 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6Mbps
IEEE 802.11n (20MHz): up to 150Mbps
IEEE 802.11n (40MHz): up to 300Mbp |
| Medye Erişim Kontrolü |
CSMA / CA |
| Modülasyon |
Transmission/Emission Type: DSSS / OFDM
Data modulation type: OFDM with BPSK, QPSK, 16-QAM, 64-QAM,
DBPSK, DQPSK, CCK |
| Band Genişliği |
2.412GHz ~ 2.484GHz |
| Çalışma Kanalları |
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels) |
| RF Output Power (Max.) |
IEEE 802.11b/g: 27 ± 1.5dBm
IEEE 802.11n: 25 ± 1.5dBm |
| Alıcı Hassasiyeti |
IEEE 802.11b: -95/ -94/ -92/ -90dBm (1/ 2/ 5.5/ 11Mbps)
IEEE 802.11g: -90/ -82/ -80/ -75dBm (6/ 24/ 36/ 54Mbps)
IEEE 802.11n: -91/ -83/ -74/ -89/ -80/ -72dBm (MCS 0/ 3/ 6/ 9/ 12/ 15) |
| Output Power Control |
3~27dBm |
| Software Features |
| LAN |
Built-in DHCP server supporting static IP address distributing
Supports 802.1d STP (Spanning Tree) |
| WAN |
- Static IP
- Dynamic IP
- PPPoE
- PPTP
- L2TP
- IPSec
|
| Çalışma Modu |
|
| Firewall |
NAT firewall with SPI (Stateful Packet Inspection)
Built-in NAT server supporting Virtual Server and DMZ
Built-in firewall with Port / IP address / MAC / URL filtering |
| Kablosuz Mod |
- AP
- Client
- WDS PTP
- WDS PTMP
- WDS Repeater (AP+WDS)
|
| Kanal Genişliği |
20MHz / 40MHz |
| Wireless Isolation |
Enables isolation of each connected wireless client from communicating with each other mutually. |
| Şifreleme |
64/128-bits WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 802.1X |
| Kablosuz Güvenlik |
Provides wireless LAN ACL (Access Control List) filtering
Wireless MAC address filtering
Supports WPS (Wi-Fi Protected Setup )
Enable / Disable SSID Broadcast |
| Multiple SSID |
Up to 2 |
| Max. Wireless Client |
40 |
| Max. WDS AP |
8 |
| Max. Wired Client |
60 |
| WMM |
Supports Wi-Fi Multimedia |
| QoS |
Supports Quality of Service for bandwidth control |
| NTP |
Network Time Management |
| Yönetim |
Web UI, DHCP Client, Configuration Backup & Restore, Dynamic DNS, SNMP |
| Diagnostic tool |
System Log, Ping Watchdog |
| Mekanik ve Güç |
| IP Sınıfı |
IP67 |
| Materyal |
Aluminum |
| Ölçüler (W x D x H) |
320 x 27.5 x 320 mm |
| Ağırlık |
2.4kg |
| Installation |
Pole mounting or Wall mounting |
| Güç Gereksinimi |
AP: IEEE 802.3af/at PoE / 48VDC input (PoE Injector included)
PoE Injector: 100~240VAC |
| Güç Tüketimi |
7.68W |
| Çevresel Özellikler |
| Çalışma Sıcaklığı |
-30~75 Degree C |
| Çalışma Nem Oranı |
10~95% non-condensing |
