| Video Özellikleri |
| Desteklenen Video Uzantıları |
H.264 / MPEG-4 / M-JPEG |
| Video Çözünürlüğü |
4CIF (D1), CIF, QCIF |
| Frame Rate |
30/25 (NTSC/PAL) fps in all resolutions |
| Resim |
AE, AWB
3D Noise reduction
Color, brightness, sharpness, contrast
Mirror / Flip
8 Privacy Masks
Text, time and date overlay |
| Streaming |
Simultaneously multi-profile streaming
Streaming over UDP, TCP, or HTTP / HTTPS
M-JPEG streaming over HTTP (server push)
Supports 3GPP mobile surveillance (MPEG4)
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4 / H.264)
ROI |
| Ses |
| Audio Streaming |
Two-Way Audio |
| Audio Compression |
RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR |
| Microfon |
External microphone input |
| Audio Output |
Adjustable audio output gain |
| Network ve Konfigürasyon |
| Standartlar |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX |
| Protokol |
IPv4, IPv6, TCP/IP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, ICMP, Samba |
| Güvenlik |
Password protection, IP address filtering, HTTPS encrypted data transmission, user access log |
| Kullanıcılar |
20 clients on-line monitoring at the same time |
| Sistem Entegrasyonu |
| Uygulama Programlama Arayüzü |
Open API for software integration
ONVIF Compliant |
| Alarm Tetikliyicileri |
Intelligent video motion detection, audio detection and external input |
| Alarm Events |
File upload via FTP, Samba to NAS, SD card or email
Notification via email, HTTP, and TCP
External output activation
Audio alerting output
Pre- and post-alarm buffering |
| Çevresel Özellikler |
| Güç Gereksinimi |
5V DC, 2A |
| Güç Tüketimi |
4W (Max.) |
| Çalışma Sıcaklığı |
0 ~ 40 Degree C |
| Çalışma Nem Oranı |
20 ~ 80% (non-condensing) |
| Ağırlık (includes LENS) |
215g |
| Ölçüler (W x D x H) |
94 x 70 x 26 mm |
| Emisyon |
CE, FCC |
| Konnektör |
10/100Mbps Ethernet, RJ-45
BNC connector, 75 ohm impedance
DC power jack
Terminal block for 1 alarm input and 1 output
RS-485 interface for pan/tilt scanners control
External MIC input
Composite video / audio output
Micro SD/SDHC card (Max 32GB, Class 6)
Factory default reset |
